Dimensions
Main unit
- Height: 104 mm
- Width: 400 mm
- Depth: 85 mm
- Weight: 1.04 kg
Remote Control
- Height: 83 mm
- Width: 83 mm
- Depth: 10 mm
System Requirements
Windows® 7, Windows 8.1, or Windows 10macOS 10.10 or higherUSB 2.0 prt (USB 3.0 Port and cable required for 4K video)RIGHTSENSE TECHNOLOGIES
- Advanced technologies and design innovations that make video collaboration easy and automatic.
RightLight
- Low-light compensation
- Video noise reduction
- Low-light saturation optimization
RightSight
- Human figure detection
- Auto-frame participants at meeting start
- Auto-frame participants on-demand
- Auto-reframe when participants enter, leave, or change positions
RightSound
- Machine learning AI trained to distinguish human speech from other sounds
- AEC (Acoustic Echo Cancellation)
- VAD (Voice Activity Detector)
- Background noise suppression
- Auto-level loud and soft voices
- Peak-limiting algorithm eliminates even momentary speaker clipping to prevent distortion
- Anti-vibration enclosure
COMPATIBILITY AND INTEGRATIONS
- Plug-and-play USB connectivity
- Certified for Skype™ for Business and Microsoft Teams
- Zoom™ Certified
- Fuze™ Certified
- Certified for Google Hangouts Meet Hardware
- Microsoft Cortana®
- Cisco Jabber®
- Compatible with BlueJeans, BroadSoft™, GoToMeeting™, Vidyo™, and other video conferencing, recording, and broadcasting applications that support USB cameras
Technical Specifications
Camera
- Custom Logitech lens with 5x HD zoom and motorized pan (+/- 25°) and tilt (+/- 15°)
- Field of View: Diagonal: 120°, Horizontal: 113°, Vertical: 80.7°
- Total Room Coverage (field of view + pan and tilt): 163° wide x 110° tall
- 3 camera position presets
- RightSight auto-framing: Requires Windows 10 64-bit or macOS 10.14 or higher
Video Performance
- 4K Ultra HD video calling (up to 3840 x 2160 pixels @ 30 fps with customer-supplied USB 3.0 cable)
- 1080p Full HD video calling (up to 1920 x 1080 pixels @ 30 fps)
- 720p HD video calling (up to 1280 x 720 pixels @ 30 fps)
Microphone
- Integrated microphone with 3 beamforming elements
- Pickup Range
- MeetUp: 4 m
- With optional Expansion Mic: 5 m
- Sensitivity: -27 dB
- Microphone frequency response: 90Hz-16KHz for full voice reproduction and high intelligibility without noise
- Beamforming performance: Factory-paired, very low distortion broadside beamforming algorithm steers the microphones directly at the talker for the best voice pickup and noise reduction
- AEC (Acoustic Echo Cancellation)
- VAD (Voice Activity Detector)
- Microphone background noise suppression
- Microphone date rate: 32KHz sampling rate
- Recommended # of participants: 6
- Recommended # of participants with expansion mic: 8
Speaker
- Volume adjustable to 95 dB SPL at 1/2 meter peak
- Speaker sensitivity 86.5+/-3dB SPL at 1/2 meter
- Distortion: 200-300Hz < 3%, 3000 Hz -10KHz < 1%
- Patent-pending anti-vibration enclosure improves voice clarity while limiting sound transmission to adjacent spaces
